Reference: 3511291B
set of segments Ø67mm MALOSSI piston d.67mm kit 166cc motorcycle 125cc 4 stroke
Id'al for maintaining your kit 67mm diameter!
Banner
Attention, part not approved on the road, prohibited on public roads, does not respect the engine capacity of 125cc! In addition to this, you need to know more about it.
High quality, from its MALOSSI brand as much as from its design! This kit offers a lot of torque and power thanks to its cylinder pushed to 167cc real (against 125cc for the origin), the diameter of the whole is therefore 67mm! Delivered with an unbridled CDI box which takes the injection parameters to offer the right air / fuel ratio to the engine, the box also retouches the rev limiter! The enselbme therefore offers you 1000 more revolutions to have fun in the red zone, which means that by passing your upper gear, you are still in the power regime. The cylinder is made of aluminum, the piston is extra compact with three segments but also lightened and reinforced with enlarged heat exchange surfaces, the segments are special for optimum resistance, minimum friction and maximum compression. Clearly enough to increase the power radically in all serenity with quality equipment. In addition to this, you need to know more about it.
Finally, the electronic box called Force Master 2 is programmed with 4 different curves which influence and regulate the fuel flow for each, which allows to have excellent carburation / fuel settings in each condition and programming levels.
Do not hesitate to download the official PDF from MALOSSI explaining from A to Z everything you need to know about this kit, the electronic box and more! The piston in combination with the original cylinder head offers a great compression ratio. You should only use SP98, a sport exhaust like the TURBOKIT without catalyst (complete line) is strongly recommended! Open up your air box to take in more air (or install a sports filter). A sprocket with one or two more teeth is recommended!
FORCE MASTER 2 electronic unit characteristics:
- Carburetion adjustment possible
- ± 20% at min / medium / max
- Lap limiter: + 1000 rpm
- 4 different programs:
--Curve 0: original cylinder, original cams, MALOSSI muffler with DB KILLER
--Curve 1: MALOSSI cylinder, original cams, original muffler
--Curve 2: Malossi cylinder, original cams, MALOSSI exhaust with DB KILLER
- Curve 3: MALOSSI cylinder, MALOSSI cams, MALOSSI exhaust with DB KILLER, MALOSSI air filter
This pack contains :
-High-end aluminum cylinder Ø67mm
-Compact aluminum piston, reinforced and lightened d.67mm
-3 segments d.67mm special for increased compression (1 rectangular and 2 scrapers)
-Piston axis Ø15x08x46mm
-2 Piston clips in C Ø15 X 1mm reinforced
- Engine gaskets
-FORCE MASTER 2 electronic box MALOSSI
-Notice
- Stickers
This kit is installed on EURO 3 and EURO 4:
APRILIA RS4 125 ie 4T LC euro 3
APRILIA TUONO 125 4T
APRILIA SX 125 4T
DERBI Senda DRD 4V R - SM 125 ie 4T LC euro 3
DERBI TERRA - TERRA Adventure 4V 125 ie 4T LC euro 3
DERBI MULHACEN 125cc 4S
DERBI GPR 125cc 4T
RIEJU CENTURY 125 (be careful, fitting the reprogramming box can pose a problem)
APRILIA RS 125 ie 4T LC euro 4 2019-> (M545M)
APRILIA RS Replica GP 125 ie 4T LC euro 4 2019->
APRILIA RX 125 ie 4T LC euro 4 2019->
APRILIA SX 125 ie 4T LC euro 4 2018-> (M545M)
APRILIA TUONO 125 ie 4T LC euro 4 2019->
And many other machines! We recommend a +1 or 2 tooth pinion, an exhaust without catalyst and a sport filter (modification of the original airbox) with this kit!
