Reference: AP0613101
APRILIA cylinder head cover for APRILIA RS 125cc Rotax 122 and 123 engine from 1996 to 2012
Ideal in case of breakage or veiling for a perfect refurbishment.
Banner
ITALKIT competition cylinder head stud CNC machined in high quality AL 7075-T6 aluminum in Spain. The high compression type chamber is semi-hemispherical in shape for maximum performance. The heat exchange is also better for better cooling and therefore, more performance!
-For a 1.40mm squish, you will have a chamber volume of 10.7cc excluding the spark plug thread, i.e. a compression ratio of 14: 1 (0.30mm base gasket) "torque-type setting"
-For a 1.60mm squish, you will have a chamber volume of 11.2cc excluding the spark plug thread, i.e. a compression ratio of 13.41: 1 (0.50mm base gasket) "high speed setting / point"
To calculate the volume with the spark plug thread, add 2cc!
Recommended cylinder head gasket Ø64mm X 2mm and Ø23 X 2.5mm as the original, to be installed with the original cylinder head cover!
Mounts on :
ROTAX 122 engine
ROTAX 123 engine
APRILIA AF1 125cc
APRILIA AF1 125cc FUTURA
APRILIA AF1 125cc REPLICA
APRILIA AF1 125cc SINTESI
APRILIA EUROPA 125cc
APRILIA PEGASO 125cc
APRILIA RED ROSE 125cc
APRILIA RS 125cc
APRILIA RS 125cc EXTREMA
APRILIA RX 125R
APRILIA SPORT 125cc
APRILIA SX 125cc
APRILIA TUAREG RALLY 125cc
APRILIA TUAREG WIND 125cc
HM CRE 125cc
HM DERAPAGE 125cc
And many other 125cc motorcycles.
Reference: AP0613101
Ideal in case of breakage or veiling for a perfect refurbishment.
Reference: 065304
A spare cylinder head from ATHENA high-end. Ideal in case of wear of your cylinder head for kit 190cc ATHENA.
Reference: S410485308006
Large diameter cylinder head stud, ideal in the event of impact, breakage... For a refurbishment guaranteed on your ATHENA Racing 170cc kit.
Reference: S410485308005
Replacement cylinder head stud for 125cc Ø56mm ATHENA Racing kit, high quality with high compression chamber.
Reference: 211.0214
Replacement cylinder head for 154cc kit on ROTAX 122, 123, APRILIA RS 125cc, RX, SX, HM ...
Reference: S410485308004
Ideal cylinder head cover in the event of impact, breakage... For a refurbishment guaranteed on your ATHENA Racing 125cc kit.
Reference: 38 7253
The head MALSSSI premium for your 125cc engine.
Reference: CU.01.140.1
125cc 2T motorcycle engine racing cylinder head with ROTAX 122 or 123 engine with ITALKIT 140cc cylinder!
Reference: 066604
Spare bolt from ATHENA. Ideal in case of wear of your cylinder head for kit 125cc ATHENA Honda motorcycle engine.
Reference: CU.01.125.2
Competition cylinder head for 125cc 2T motorcycle engine with ROTAX 122 or 123 engine with ITALKIT or ORIGIN cylinder prepared with racing piston!
