ITALKIT original size reinforced crankshaft connecting rod (Length 106.5mm, crankpin Ø32mm) for HONDA MOTORCYCLE XR 250 4T

Here is the reinforced connecting rod from ITALKIT , specially designed for your HONDA XR 250 4T motocross bike.

This model is reinforced with a connecting rod length of 106.5mm, its lubrication is improved. The crank pin is Ø32mm by length 56mm.

Length between centers/center to center (mm): 106.5

Øint Connecting Rod/Connecting Rod Bore (mm):17

Øint Connecting Rod Head/Connecting Rod Bore (mm):41

Crank Foot Width/Small End Bore Width (mm):18

Crank Head Width / Connecting Rod Bore Width (mm): 18

Ø of crankshaft bolts/Ø of crank pin (mm): 32

Crankshaft Bolt Length/Crank Pin Length(mm):56

Piston pin cage/small end bearing (mm):

Crankshaft axle cage/big end bearing (mm):

Washers/Conrod Washers(mm):1

Mounts on:

HONDA XR 250 4T
