Reference: 9.117.86.1.015
Crankshaft, connecting rod assembly RITO original race 39,1mm for MINARELLI P6 engine
Original 39.1mm stroke crankshaft for MINARELLI P6 engine.
Banner
High quality RITO reinforced connecting rod for MINARELLI P5R engines. Ideal for refurbishing your crankshaft in all quality and serenity!
Length: 85mm
Crank pin Ø 16mm
Big end width (crankpin side) 11.8mm
Conrod smallest width (piston side) 14mm
Crankpin length 40.3mm
Outer Ø of the big end cage (crank pin) 22mm
Outer Ø of the small end cage (piston) 15mm
Small end cage (piston) supplied: 12X15X15mm
Big end cage (crank pin) supplied: 16X22X11.8mm
Reference: 9.117.86.1.015
Original 39.1mm stroke crankshaft for MINARELLI P6 engine.
Reference: 9.149.09.1.012
39.7mm original stroke crankshaft for SACHS engine.
Reference: 09.117.85.1.015
Original 39.1mm stroke crankshaft for MINARELLI CORSA CORTA engine.
Reference: AMT 032A
High quality crankshaft, special 42mm long stroke model with 85mm connecting rod.
Reference: 9.149.23.1.012
Long stroke crankshaft 42mm for 3 speed SACHS engine by hand.
Reference: 9.096.21.1.013
Crankshaft for KREIDLER, FLORETT ...
Reference: 9.149.19.1.012
42mm long stroke crankshaft for 2 speed SACHS engine.
Reference: 9.117.25.1.115
Rod reinforced in 85mm, crank pin Ø16mm for MINARELLI P6, P6R and RV6.
Reference: AMT 256A
Very high quality! High-end materials, an extraordinary and very rare piece.
Reference: 6030071
Here is the Crankshaft of original type Top Racing for Zundapp 3 & 4 Speed C 50 GTS CS CX ZD ZL NEU ....
Reference: 9.149.21.1.012
Long stroke crankshaft 42mm for SACHS engine with 3 speeds at feet.
Reference: 9.096.22.1.013
Crankshaft for KREIDLER, FLORETT ...
Reference: 9.033.21.1.015
44mm long stroke crankshaft for CASAL engine with 6 speed ratios.
Reference: 9.096.23.1.013
Crankshaft for KREIDLER, FLORETT ...
Reference: 6030039
Crankshaft for old engines CASAL has 4 and 5 speeds 50 2T.
Reference: 53488.14
A crankshaft of very high quality cortex 44mm for your MINARELLI P6.
