TOP PERFORMANCES RACING double curve internal rotor ignition SELETTRA scooter PIAGGIO / GILERA H2O (Typhoon, NRG...)

99ARI0300

Variable advance ignition and internal racing rotor for PIAGGIO SCOOTER 50cc liquid cooling.

€299.99
Quantity
Shipping in 8 to 15 days depending on factory arrivals TOP PERFORMANCES

Description

Here is the TOP PERFORMANCES RACING internal rotor ignition SELETTRA scooter PIAGGIO / GILERA H2O (Typhoon, NRG ...)

Superb quality, the ignition comes from the racing factory branch of TOP PERFORMANCES . Only intended for 50cc 2T liquid scooters (H20) for circuit use. Just like TM on KZ Karting engines, MALOSSI MHR on its RC ONE engines, ITALKIT on its competition machines, TPR has chosen the latest generation SELETTRA as its base, with a double-curved Ø58mm rotor!

The ignition kit consists of a variable advance digital electronic unit equipped with 2 preset maps with a system based on uP Freescale 8 Bit 40 MHz for reduced calculation times as well as excellent stability and precision in ignition. advance, whose hardware architecture guarantees high immunity to disturbances.

The electronic box incorporates a high voltage coil with wiring with temperature class 125°C and a rotor-stator unit with high permeability monolithic magnetic circuit with Ø 58 rotor with permanent neodymium magnets with Automotive class wiring and waterproof connectors, IP67 certified with retention block.

The kit is completed with a CNC adapter in anodized anticorodal and an inertial mass in non-magnetic AISI 316 steel.

Obviously, to provide maximum power to the engine, the ignition does not produce energy for the headlights, the double curve system works very simply by plugging or unplugging a cable. One curve is more tuned to very powerful engines at high revs (curve 1), the other curve, less aggressive, is recommended on more torquey engines or air-cooled engines, cast iron... The new computer integrated into the chip is very fast and it allows the production of a nice smooth curve!

The advance is adjusted at 0° all stacks, so exactly at TDC the two marks face to face!

Will be provided :

- 1x Stator group

- 1x Inner Rotor

- 1x Digital electronic box

- 1x Inertial mass

- 1x Stator adapter

- 2x TCHC M6x18 screws

- 2x TCHC M5x35 screws

- 1x TCHC M5x20 screw

- 3x Flat washer Ø5

- 3x TFHC M5x14 screws

- 1x Nut M10x1.25

- 1x Sheet metal washer Ø10mm

Mounts on:

APRILIA SCARABEO 2T 50 2T 14

APRILIA SR CARBURETTOR 50 2T 14

APRILIA SR MOTARD 50 2T 12 14

APRILIA SR R 50 2T 04 09

APRILIA SR R FACTORY CARBURETOR 50 2T 10 14

APRILIA SR R FACTORY IE 50 2T 10 14

APRILIA SR STREET CARBURETOR 50 2T 03 12

DERBI GP1 50 2T 01 02

DERBI GP1 50 2T 03 03

DERBI GP1 EU 2 50 2T 05 05

DERBI GP1 OPEN EU2 50 2T 06 09

DERBI GP1 RACE EU2 50 2T 05 07

GILERA DNA 50 2T 00 02

GILERA DNA 50 2T 05 07

GILERA DNA GP EXPERIENCE 50 2T 03 04

GILERA RUNNER 50 2T 97 00

GILERA POGGIALI RUNNER 50 2T 02

GILERA RUNNER SP 50 2T 02 04

GILERA RUNNER SP 50 2T 05 06

GILERA RUNNER SP 50 2T 07 07

GILERA RUNNER SP 50 2T 10 12

GILERA RUNNER SP SPECIAL EDITION 50 2T 07

GILERA RUNNER SP ST & SIMONCELLI 50 2T 08 09

PIAGGIO NRG 50 2T 94 96

PIAGGIO NRG EXTREME LC 50 2T 99 00

PIAGGIO NRG MC3 50 2T 01 04

PIAGGIO NRG POWER DD 50 2T 05

PIAGGIO NRG POWER DD 50 2T 06

PIAGGIO NRG POWER DD 50 2T 07 17

PIAGGIO NRG POWER DD SPECIAL SERIES 50 2T 07 12

PIAGGIO NRG RST MC2 50 2T 96 98

PIAGGIO NTT 50 2T 95 96

PIAGGIO QUARTZ 50 2T 92 96

PIAGGIO ZIP 2T 50 2T 08 13

PIAGGIO LC-ZIP 50 2T 00 04

PIAGGIO SP ZIP 50 2T 96 00

PIAGGIO SP ZIP 50 2T 01 04

PIAGGIO ZIP SP EURO 2 50 2T 06 13
