The SHA 14.14 L carburetor is a simple model, less known than the 15.15 but just as functional. With its diameter of 14mm it will be more than sufficient on mopeds (PEUGEOT 103, MBK 51 ...) small original configurations ... If you are looking for a carburetor that does not have separate lubrication, very easy to adjust, solid, inexpensive, which consumes little and makes little noise! This carburetor will be perfect.
This L version is a version with manual cable choke (with lever) which does not have a separate greasing inlet with a straight outlet aluminum fuel inlet pipette. There is also the standard L version. This carburetor has a horizontal throttle cable inlet (bent at 90 °), you can easily ask vertical or other arrivals.
High quality guaranteed, genuine DELLORTO carburettor, it was even used as an original fitment on some machines! The starter is therefore manual but with an automatic system which allows the latter to be removed thanks to a spring + valve system. Equipped with an integrated fuel filter with its aluminum pipette, straight diameter for Ø6mm hose (5mm in forcing).
This carburetor is equipped with these parameters :
-Boisseau size 12
-Standard DELLORTO 68 nozzle in small steps
Summary :
-Diameter for fixing the carburetor on the intake pipe: 19mm
-Mounting: rigid
-Separate greasing: no
-Diameter fixing air filter 59mm
-Starter lever with automatic stop
-Diameter of the carburetor 14mm
-Fuel filter integrated into the carburetor with straight aluminum pipette
